Description
Max. prop shaft output 73.6 kW / 100 hp
Full throttle operating range 5000~6000 r/min
Idling speed 750 ± 50 r/min
Fuel consumption 36.9 l/h @6000 r/min
Engine type 4-Stroke, 16-Valve, SOHC, In-line 4
Displacement 1832 cm³
Bore × Stroke 81.0 × 88.9 mm
Compression ratio 10.0 :1
Starting enrichment Fuel Injection
Fuel induction system Electronic Fuel Injection (EFI)
Fuel tank —
Lubrication system Wet sump
Engine oil capacity 3.2/3.0 ℓ (with / without oil filter replacement)
Ignition system TCI Micro-computer
Ignition timing BTDC 8.5 ~ BTDC 23.0 deg.
Spark Plug LKR6E-9N
Engine Start Electronic Starter
Alternator 35 A (battery charge: 21 A)
Cooling system Raw-water, thermostatically controlled
Steering Remote Control
Steering Angle (maximum) 35° from center, either direction
Mounting Centers –
Trim Control System Power trim and tilt
Trim / Shallow water drive Сontinuously variable
Degree of Trim -4° through +16°
Degree of Tilt 70°
Gear shift Forward-Neutral-Reverse
Gear ratio 2.15 (28/13)
Gear oil capaciti 0.760 ℓ
Propeller rotation Clockwise
Propeller hub K
Engine transom height (Shaft length) L: 516 mm (20.3 inch)
Boat transom height L: 508 mm
Dry weight 170,0 kg
